SPECIFICATION TABLE
| ITEM | DESCRIPTION | |
| INPUT | Voltage range | AC400V±10% ,3 |
| Working frequency | 45-65HZ | |
| The power factor | ≥0.99 | |
| Input current | 0-400A | |
| Input cable length | NA (as per site requirements) | |
| OUTPUT | Power | 240KW |
| Auxiliary power supply | GB/T:12V/24V | |
| Voltage range | 200-750V DC 150-1000 | |
| Output current | GB/T:0-250A | |
| Charger mode | Single plug full power/Dual plugs AB equalization | |
| Charger plug | Single plug/ Dual plugs | |
| Cable | Default 6 meters | |
| WORKINGCONDITIONS | Temperature range | -40~50℃ |
| Humidity range | 5~90RH%；（non-condensation） | |
| The altitude | 2000M | |
| Temperature range | Indoor/outdoor | |
| DIMENSIONS ANDPROTECTION | Machine size(mm) | 800 x 750 x 1900 mm |
| Weight | 398 Kg | |
| IP | IP55 | |
